Coils and RPM's?

Ozpulse created the topic: Coils and RPM's?

I keep hearing that certain coils on weedy motors limit the rpm's they are capable of.
If this is true what coils should us poor people be on the lookout for?
Is there someplace we can look to find the info on our coils?
Can our coils be modded for more rpm?
Can we just put a better coil on for better top end?

Thanks again guys! ;)

Awwwww! Your little engine is sooooo cute!
#13015

Please Log in or Create an account to join the conversation.

Scott replied the topic: Re:Coils and RPM's?

Your question is a valid one but too vague in what or who's engine the coil is your asking about.

Issue with the less expensive engines generally is an ignition system that is NOT a CDI type and has limits to how many cycles per second it can generate current and collapse creating the spark. Most of these systems won't regenerate when approaching the 10K range.
Some manufacturers will have coils specs set up with a peak rpm limit as a mechanical failure safety preventing over rev.

With so many of the Zenoahs of old ( G230pum ) and newer G260pum used around, do yourself a BIG service by buying a decent engine while being frugal with the rest of your building etc ;)

2 stroke Engine Tech of 30+ years, Prop tweeker, Chronic tinkerholic, Home of Motor Heads RC Racing Engines ...
8 time NAMBA National 6 lap heat racing record holder.
#13024

Please Log in or Create an account to join the conversation.

marc replied the topic: Re:Coils and RPM's?

<strong>Scott wrote:</strong>
I have to agree 100% with Scott on this!

Modelgasboats.com - Home of the WARPATH Riggers!

Follow Modelgasboats.com on FACEBOOK - CLICK HERE
"
#13028

Please Log in or Create an account to join the conversation.

isuzudude replied the topic: Re:Coils and RPM's?

Hey Chad, while you're waiting to get the 50cc beast up and running. Put the cdi I sent ya on it and give a spin. Who knows, if it kicks butt, let me know, and I'll send ya another unit to put back on the 50 B) Keep tryin Dude!!! ;)
#13034

Please Log in or Create an account to join the conversation.

road replied the topic: Re:Coils and RPM's?

im living proof that building a homelite engine is a long and teedious task only to get minimal performance from my efforts. (i messed up the timing) after 2 years of modifing it, i hate to say i gave in and purchased a stock zenoah g260pum.
but hey i do have an awsome looking paper weight for my desk at work.

with that said
i learned alot building a homelite, and yes there are some better parts than others , depending on year it was made . etc..

Jim from Jims r/c boat dock is one of the guru's that have alot of success with homies also Tony from warehouse hobbies. if your on a buget go for it, these guys will be glad to help you.

road
#13683
Attachments:

Please Log in or Create an account to join the conversation.
